Merida Scultura 10K

• Super-light CF5 carbon frame (approx. 822 g – in size M) with race-proven geometry
• SRAM Red 12-speed eTAP AXS wireless group set
• Power meter
• MERIDA TEAM SL 1P one-piece cockpit
• ZIPP 353 NSW wheelset with Continental 5000S TR 28 mm tyres
• MERIDA TEAM SL II carbon seat post and DISC COOLER technology
• Approximate weight – 6,7kg

Sizes available – Small / Medium / Large / X Large

Frame Size	3XS	XXS	XS	S	M	L	XL
Tyre Sizes	28″	28″	28″	28″	28″	28″	28″
ST seat tube [mm]	400	435	458	481	501	521	550
TT top tube [mm]	505	520	535	545	560	575	590
CS chain stay length [mm]	408	408	408	408	408	408	408
HTA head tube angle [°]	70.5	70.5	72	72.5	73.5	73.5	74
STA seat tube angle [°]	75.5	74.5	74	74	73.5	73	73
BD bottom bracket drop [mm]	70	70	70	66	66	66	66
HT head tube [mm]	100	105	112	128	140	155	176
FL fork length [mm]	385	385	385	385	385	385	385
R reach [mm]	373	377	383	390	395	400	409
S stack [mm]	512	517	529	542	557	571	593
WB wheel base [mm]	979	985	982	989	990	1000	1010
SH stand over height [mm]	700	721	745	765	782	800	823
